Description
Finally a complete six shooter knuckle option! We put these kits together with all available knuckle stud options, from stock, to mid-grade, to the strongest ARP Knuckle Studs available. Kits come complete with all knuckle hardware top and bottom, as well as optional lower knuckle caps. You can reuse your stock lower caps, or if you are running a trunnion bearing eliminator kit, they include new lower caps. All variations include stock lower knuckle studs. There is no need to run stronger studs on the bottom, as they are never loaded in sheer. If you have any questions about these knuckle kits or the available options, give us a call!
Kits include:
- Six Stud Knuckles (2)
- Six Stud High Steer Arms (2)
- 6 and 4 Stud Knuckle Shims
- All Knuckle Studs, Nuts, Washers and Cone Washers
- Optional lower knuckle caps
Additional parts you probably need:
- Trail Safe Wiper Seal Kit
- Steering Stop Bolt Kit
- Spindle Stud Kit or OEM Toyota Spindle Bolts
- Spindles
- Wheel Hubs
- Spindle Nut Kits
- Locking Hubs or Drive Flanges
- Knuckle Rebuild Kit
- Red Threadlock
Recommended torque specs:
- Knuckle stud into knuckle: Snug, DO NOT OVERTIGHTEN
- Stock Knuckle stud nuts: 71 ft-lbs
- Super Metal Knuckle Studs nuts: 80 ft-lbs
- ARP Knuckle Stud nuts (black or gold): 100 ft-lbs
